RCS-N9030 Refrigerant Electronic Large Flow Programmable Charging Precision Electronic Digital Balance Scale Calibration Weight

RCS-N9030 Refrigerant Electronic Large Flow Programmable Charging Precision Electronic Digital Balance Scale Calibration WeightSpecification: 1.Model: RCS-N9030 2.Maximum weighing capacity: 100KGS / 220LB / 220LB.00.0OZ 3.Unit conversion: KGS/LBS/OZ 4.Accuracy: +/-0.5% of reading 5.Resolution: 0.25 OZ / 5G 6.Weighing pan size: 223*223mm 7.Power supply: 7.5VDC (DC 7.5V) 8.Battery life: 60 hours continuous use 9.Operating temperature: 50F – 122F (10°C – 50°C) 10.Weight: 2.74kg 11.Dimensions: 23.2cm * 23.2cm *5.8cm Operating steps: 1.Remove the product from the box and place it on a level, stable surface. 2. Press the ON/OFF button to turn on the scale. 3.Place the cylinder to be cooled in the center of the electronic scale tray. 4.Connect one end of the dosing tube to the 'INLET' and the other end to the refrigerant cylinder. 5. Connect one end of another dosing pipe to the other end of ‘OUTLET’ to connect to the air conditioning system or the refrigerant dosing valve 6. Open a small amount of refrigerant cylinder switch to remove air from the filling tube 7. Press the ‘SET’ button, the LCD screen will automatically display zero 8. Increase/decrease the set weight by pressing the red/green arrow button repeatedly. If you press and hold the red/green arrow button for 5 seconds, it will speed up/decrease the set weight. After setting the weight, press ‘ RUN/STOP ’ to start adding liquid, and stop automatically after adding liquid. 9.Press the SET button once and the scale returns to the weighing mode.

• Maximum weighing capacity: 100KGS / 220LB / 220LB.00.0OZ
• Unit conversion: KGS/LBS/OZ
• Accuracy: +/-0.5% of reading
• Weighing pan size: 223*223mm
• Operating temperature: 50F – 122F (10°C – 50°C)
